Sanitary Side-clamp non retention ball valve

Sanitary Side-clamp non retention ball valve


    Sanitary threaded 3 way ball valve, sanitary ball valve, hygienic ball valve, sanitary non-retention ball valve, hygienic ball valve, hygienic butterfly type ball valve

Sanitary Side-clamp non retention ball valve

The completelyfull-through design for valve chamber can not bring any liquid resistance,
so it is the best choice for dealing with sticky or grain liquid.

Features:
High precise casting body
Pressure: 10bar
Temperature: -60~ 180 degree
Body type: Side clamp type or middle clamp type
Working mode: Manual type, electrical type, pneumatic type
Gaskets: PTFE EPDM
Non retaining, Easy cleaning, easy maintenance, light weight,

Connection end: Weld, tri-clamped,
Standard: DIN, SMS
Material: SS304, SS316L
Inside surface finish: Ra0.4

Outside surface finish: Ra 0.6
Size: DN15-DN65 , 1/2”-2 1/2”
Application: Food, beverage, dairy, pharmacy, chemical or any food processing industries
