Sanitary Pneumatic 3 piece ball valve

Sanitary Pneumatic 3 piece ball valve


    Sanitary threaded 3 way ball valve, sanitary ball valve, hygienic ball valve, sanitary non-retention ball valve, hygienic ball valve, hygienic butterfly type ball valve

Sanitary Pneumatic 3 piece ball valve

3 piece Hygienic ball valve
Stainless steel 3 piece hygienic ball valve
Features:

All line design,in order to reduce pipeline rapids and pressure drop
High precise casting body and flange
Full bore type and non dead angle design
Pressure: 1000PSI
Temperature: -60~ 180 degree
Working mode: Manual type, electrical type, pneumatic type
Gaskets: PTFE EPDM
Easy cleaning, easy maintenance,

Connection end: Weld, tri-clamped, union, flange,male threading, female threading
Standard: DIN, SMS, ISO, 3A, IDF
Material: SS304, SS316L
Inside surface finish: Ra0.4

Outside surface finish: Ra 0.6
Size: DN15-DN100 , 1/2”-4”
Application: Food, beverage, dairy, pharmacy, chemical or any food processing industries
